American battle cruiser design No. 143 dated 1 July 1915

©Warshipsresearch.blogspot.com

Requested by the General Board probably to get an impresssion of the cruiser of the future. Never built, lacked any side armour protection. If the machinery available for scouts (10ehp/ton) was satisfactory could a side armour belt of 3.75 be added in way of machinery and magazines. Dimensions 725 (waterline) x 90.0 (waterline) x 30.6 feet. Block Coefficient .527. Longitudinal coefficient .538. Speed 30 knots. Range 10 knots/8,000 nautical miles. Horsepower 41,900 ehp at 30 knots. Turbine propulsion. Number of boiler rooms 7. Armament 3x2-16”B.L.R. guns, 14-15.4cm/6” guns, 4-7.62cm/3” anti aircraft guns and 4-53.34cm/21” torpedo tubes. Heavy part of barbettes protected by 14” armour, gun turrets 16” (port)10 (sides)-5” (top)-9 ” (rear), heavy parts of conning tower 16”and protective deck in way of machinery and magazines only 5”/

Normal displacement 30,00 tons

Hull complete with fittings 14,737

Protection 3,327

Steam engineering 6,210

Reserve feed 2/3 supply 655

Battery 1,275

Ammunition and 2/3 ordnance stores 1,076

Equipment and 2/3 equipment stores 500

Outfit and 2/3 stores 710

Oil fuel 23 full supply 1,510

Source

U.S. Naval History and Heritage Command 1911-1925 Spring Styles Book. S-584-081.
